Chiller Cases

After years of working on sensitive military projects, our manufacturer has developed the ultimate high capacity, closed-loop, climate controlled, shock-mounted rack mount case. Now, high value, rack mount electronics can be protected from: overheating and freezing; dust; humidity; hazardous chemicals; fumes; unauthorized access.
Typical applications:

• Telecom: Signal Generator & Repeater Systems
• Computing: High-Performance Servers & Clusters
• Military: Command & Control (C3 & C4) Systems
• Electronic Countermeasures Equipment (ECME)
• Microwave Communications Electronics
• Remote Operation Systems
• Material Processing: On-Site Process Control Systems.

click here for brochure

The Closed-Loop A/C System Features

• High Efficiency: With thermal management right at the source;
• Environmental Protection: The atmosphere is re-circulated within case;
• Streamlined Footprint - ideal for limited space applications. No need for separate A/C unit with bulky ducting;
• Single Case Solution: Simplifies deployable applications. Ultra-rapid setup / takedown.
A/C System Features: click for image

• A/C unit incorporates a low noise / vibration rotary compressor;
• Easy to use digital controller;
• Stainless steel housing (NEMA 4X);
• Corrosion resistant coils and internal piping;
• 120V/60Hz or 230V/60Hz power configurations available;
• 10 micron, low resistance air intake filter A/C System Options;
• Optimized (MIL-Spec) air intake and exhaust filtration;
• Hazardous duty (Class 1 Div 2);
• Heater package.

Case Shell Features: click for image

• Modified Target™ Military shock-mounted STD 19 in. rack mount case;
• High-strength aluminum shell - heavy payload ready;
• Not affected by temperature extremes - will not sag, warp, blister or crack;
• I/O cable access panel engineered to your specs (MIL-Spec. connectors NOT incl.).

Case Shell Options:

• Removable cordura airflow baffle to direct airflow through rack;
• Fire retardant case insulation for improved efficiency.

Rack Features: click for image

• Standard rack heights available from 3U through 30U (1U increments);
• Standard rack depths available from 16 in. through 36 in. (1 in. increments);
• Shock / vibration attenuation for payloads ranging from 20 lbs. to over 500 lbs.;
• E.I.A. round hole and E.I.A. square hole patterns - STANDARD.

Chiller Case Specifications ------>>
